1060 Aluminum Foil
1060 Aluminum Foil Alloy: Ideal for packaging, insulation, and electrical applications due to its high conductivity and excellent corrosion resistance.
Trusted Excellence in Aluminum Metal Products, Your Reliable Industrial Partnerr
- Leading Provider of Aluminum Metal Solutions
- Number #1 Supplier in China
- Certified ISO 9001:2008
In the ever-evolving world of packaging and insulation materials, finding versatile, efficient, and cost-effective solutions is crucial. 1060 aluminum foil emerges as an exceptional choice, renowned for its outstanding properties and versatility in a wide range of applications.
Overview of 1060 Aluminum Foil
1060 aluminum foil is a top-tier material known for its high purity, excellent formability, and corrosion resistance. Its versatility makes it ideal for applications ranging from packaging to insulation, offering a reliable solution across various industries.
The 1060 alloy foil is one of the key products in our Heavy Duty industrial aluminum foil series.
Product Features
- Purity: 1060 aluminum foil exhibits high purity levels, ensuring minimal impurities and excellent material integrity.
- Formability: With its superior formability, 1060 aluminum foil can be easily shaped, folded, and manipulated to suit specific packaging or insulation needs.
- Corrosion Resistance: The inherent corrosion resistance of 1060 aluminum foil ensures long-term durability, even in challenging environments.
- Thermal Conductivity: This alloy boasts excellent thermal conductivity, making it an ideal choice for heat transfer applications in insulation.
Product Parameters
To fully comprehend the capabilities of 1060 aluminum foil, let’s explore its key product parameters:
| Parameter | Value |
|---|---|
| Thickness | 0.005 mm - 0.2 mm |
| Width | 100 mm - 1650 mm |
| Alloy | 1060 |
| Temper | O, H14, H16, H18 |
| Surface | Bright |
| Core Material | Aluminum |
| Tensile Strength | ≥ 60 MPa |
| Elongation | ≥ 20% |
Composition Adequacy
The composition of 1060 aluminum foil is meticulously tailored to ensure optimal performance and consistency. Here’s a breakdown of its typical composition:
| Element | Composition (%) |
|---|---|
| Aluminum (Al) | ≥ 99.6 |
| Silicon (Si) | ≤ 0.25 |
| Iron (Fe) | ≤ 0.35 |
| Copper (Cu) | ≤ 0.05 |
| Magnesium (Mg) | ≤ 0.03 |
| Manganese (Mn) | ≤ 0.03 |
| Zinc (Zn) | ≤ 0.05 |
| Titanium (Ti) | ≤ 0.03 |
| Others (Each) | ≤ 0.03 |
| Others (Total) | ≤ 0.10 |
Mechanical Properties
1060 aluminum foil boasts impressive mechanical properties, contributing to its reliability and versatility:
-
Property Value Tensile Strength ≥ 60 MPa Elongation ≥ 20% Yield Strength ≥ 45 MPa
Physical Properties
In addition to its mechanical prowess, 1060 aluminum foil exhibits desirable physical properties:
-
Property Value Density 2.7 g/cm³ Melting Point ~ 660°C (1220°F) Thermal Conductivity 227 W/m·K Electrical Conductivity 62% IACS
Temperature Designations
1060 aluminum foil demonstrates remarkable thermal stability, making it suitable for various temperature ranges:
-
Temperature Designation Range Cryogenic Below -195°C (-320°F) Low Temperature -195°C to -55°C Ambient Temperature -55°C to 95°C Elevated Temperature 95°C to 205°C High Temperature 205°C to 315°C
Available Dimensions
1060 aluminum foil is available in a range of dimensions to suit diverse application needs:
| Thickness (mm) | Width (mm) | Length (m) |
|---|---|---|
| 0.005 - 0.2 | 100 - 1650 | Customizable |
Comparative Results
Comparing 1060 aluminum foil with other materials reveals its competitive advantages:
| Property | 1060 Aluminum Foil | Other Materials |
|---|---|---|
| Strength | High | Variable |
| Weight | Lightweight | Variable |
| Corrosion Resistance | Excellent | Variable |
| Formability | Excellent | Variable |
| Cost | Moderate | Variable |
Product Benefits
1060 aluminum foil offers numerous benefits that make it a preferred choice for various applications:
- Versatility: Suitable for packaging, insulation, and electrical applications.
- Cost-Effective: Provides a cost-effective solution without compromising on quality.
- Environmental Friendly: Recyclable and sustainable material option.
- Excellent Barrier Properties: Protects against moisture, light, and contaminants.
Suppliers And Price Ranges
Obtaining 1060 aluminum foil from reputable suppliers ensures quality and reliability. Here’s an overview of indicative price ranges from various suppliers:
| Supplier | Location | Price Range (USD/kg) | Minimum Order |
|---|---|---|---|
| ABC Metals Inc. | United States | $2.50 - $3.50 | 100 kg |
| Aluminum Warehouse | United States | $2.30 - $3.20 | No minimum |
| Global Aluminum | Canada | $2.60 - $3.60 | 50 kg |
| Euro Aluminum | Europe | €2.00 - €3.00 ($2.20 - $3.30) | 100 kg |
| Asia Aluminum Co. | China | ¥15 - ¥25 ($2.40 - $4.00) | 500 kg |
Applications
1060 aluminum foil finds applications across various industries, including:
- Packaging: Food packaging, pharmaceutical packaging, and insulation.
- Insulation: Thermal insulation, radiant barrier, and HVAC ducting.
- Electrical: Capacitors, transformers, and electrical panels.
- Industrial: Heat exchangers, reflectors, and decorative applications.
Frequently Asked Questions (FAQs)
- What are the primary advantages of using 1060 aluminum foil in packaging?1060 aluminum foil offers excellent barrier properties against moisture, light, and contaminants, ensuring product freshness and integrity. Its formability and heat resistance make it suitable for various packaging applications.
- Can 1060 aluminum foil be recycled?Yes, 1060 aluminum foil is highly recyclable and can be recycled repeatedly without losing its properties. Recycling aluminum foil helps conserve natural resources and reduce environmental impact.
- Is 1060 aluminum foil suitable for insulation applications? Absolutely, 1060 aluminum foil is widely used in insulation applications due to its excellent thermal conductivity and barrier properties. It effectively reflects radiant heat, making it ideal for thermal insulation and HVAC systems.
