Overview

5052 aluminum bar is a high-strength, corrosion-resistant material widely used in industrial, marine, and commercial applications. Known for its excellent formability, weldability, and superior performance, 5052 aluminum bar is the preferred choice for projects requiring reliable, lightweight, and durable material. Its adaptability and ease of use make it ideal for a wide range of applications, particularly those in harsh environments.

Product Characteristics

• High Strength: 5052 aluminum bar provides a strong balance of tensile and yield strength, making it suitable for demanding structural applications.
• Excellent Corrosion Resistance: This alloy offers outstanding resistance to atmospheric and marine environments, ensuring long-term durability.
• Good Machinability: 5052 aluminum bar can be easily machined, enabling precise fabrication of detailed components.
• Weldability: The bar can be readily welded using various techniques, ensuring strong, reliable joints.
• Versatility: Suitable for a wide range of applications, including marine, automotive, industrial, and general fabrication.
• Good Formability: 5052 aluminum can be easily formed, allowing for versatile design options and complex geometries.

Product Parameters

1. Thickness/Width:

• Available in a range of thicknesses from 1/8 inch to 8 inches and widths from 1/2 inch to 12 inches, catering to various application requirements.

2. Length:

• Standard lengths include 12 feet and 24 feet, with custom lengths available upon request.

3. Commonly Used States:

• H32, H34, H36, and other tempers based on specific application needs.

4. Chemical Composition:

• Aluminum (Al): Balance
• Magnesium (Mg): 2.2-2.8%
• Chromium (Cr): 0.15-0.35%
• Iron (Fe): 0.4% max
• Silicon (Si): 0.25% max
• Copper (Cu): 0.1% max
• Manganese (Mn): 0.1% max
• Zinc (Zn): 0.1% max
• Other Elements: 0.05% max (each), 0.15% max (total)

5. Mechanical Properties (Example for 5052-H32 Alloy):

• Tensile Strength: 31,000-40,000 psi (215-275 MPa)
• Yield Strength: 28,000 psi (193 MPa)
• Elongation: 10-12%
• Hardness (Brinell): 60 HB
• Density: 2.68 g/cm³

Applications

• Marine: Boat frames, railings, and marine hardware.
• Automotive: Fuel tanks, structural components, and heat exchangers.
• Industrial: Piping systems, structural frameworks, and conveyor systems.
• Construction: Structural supports, architectural elements, and building frameworks.
• Aerospace: Aircraft fittings and structural components.
• Consumer Goods: Furniture, sports equipment, and recreational vehicle components.

Conclusion

5052 aluminum bar from kunxin aluminum company is engineered to meet the highest standards of quality and performance. Its exceptional strength, corrosion resistance, and formability make it the preferred choice for a wide range of demanding applications. With customizable sizes and tempers, we ensure that you get the perfect material to meet your specific needs. Contact us today to learn more about our 5052 aluminum bars and how they can enhance your projects.
