5005 aluminum sheet is a versatile alloy renowned for its exceptional corrosion resistance, superior surface finish, and robust mechanical properties. Widely utilized in architectural, automotive, and industrial sectors, this alloy excels in applications demanding formability, strength, and aesthetic appeal. Its smooth finish makes it particularly suitable for anodizing and decorative purposes.

Product Characteristics

• Excellent Corrosion Resistance: Superior protection against atmospheric corrosion, ideal for outdoor applications.
• Good Formability: Easily shaped and formed, offering diverse design possibilities.
• Superior Anodizing Quality: Excellent surface finish, perfect for achieving uniform appearance through anodizing.
• Lightweight: Strong yet light, reducing overall structure weight without compromising integrity.
• Good Weldability: Readily weldable, facilitating various fabrication and assembly processes.

Product Parameters

Thickness: Range from 0.2 mm to 6.0 mm, catering to diverse application needs.

Length: Standard options of 2000 mm, 3000 mm; custom lengths available.

Width: Standard options of 1000 mm, 1220 mm, 1500 mm; custom widths available.

Commonly Used States: H14, H24, H34, and other tempers as per specific requirements.

Chemical Composition:

Aluminum (Al): Balance
Magnesium (Mg): 0.5-1.1%
Manganese (Mn): 0.0-0.2%
Iron (Fe): 0.0-0.7%
Silicon (Si): 0.0-0.3%
Copper (Cu): 0.0-0.2%
Chromium (Cr): 0.0-0.1%
Zinc (Zn): 0.0-0.25%
Other Elements: 0.05% max (each), 0.15% max (total)
Mechanical Properties (5005-H34 Alloy):

Tensile Strength: 26,000 psi (179 MPa)
Yield Strength: 21,000 psi (145 MPa)
Elongation: 10-12%
Hardness (Brinell): 45 HB
Density: 2.68 g/cm³

Applications

• Architectural: Curtain walls, cladding, roofing panels
• Automotive: Body panels, trim, interior components
• Industrial: Signage, nameplates, machine parts
• Consumer Goods: Appliances, cookware, furniture
• Marine: Boat hulls, decks, structural components
