3 16 Aluminum Sheet: Comprehensive Product Introduction

Overview

The 3 16 aluminum sheet is a highly versatile and durable material, commonly used in a wide range of applications due to its combination of strength, lightweight nature, and excellent corrosion resistance. This thickness, equivalent to approximately 4.76mm, makes it suitable for both structural and decorative purposes, offering a balance between rigidity and ease of fabrication.

Product Characteristics

Strength and Durability

The 3 16 aluminum sheet provides excellent mechanical strength, making it suitable for demanding applications where durability is a key requirement. It resists deformation under load and performs well in harsh environments.

Lightweight

Despite its robustness, the 3 16 aluminum sheet is lightweight, which reduces transportation and handling costs. This makes it an ideal choice for applications where weight savings are important, such as in the automotive, aerospace, and marine industries.

Corrosion Resistance

Aluminum is naturally resistant to corrosion, and the 3 16 aluminum sheet is no exception. It can withstand exposure to moisture, chemicals, and other corrosive elements, ensuring long-lasting performance in outdoor and marine environments.

Ease of Fabrication

The 3/16 aluminum sheet is easy to cut, form, and weld, allowing for a wide range of customization options. It is ideal for projects that require precise shaping and joining without compromising the material’s integrity.

Product Parameters

Thickness

• 3 16 inch (4.76mm)

Length and Width

• Standard sizes: 4’x8′ (1220mm x 2440mm), 4’x10′ (1220mm x 3048mm)
• Custom dimensions can be provided to suit specific project needs

Commonly Used States (Temper)

• H14: Strain-hardened, partially annealed
• H24: Strain-hardened, partially annealed with increased strength
• T6: Solution heat-treated and artificially aged for higher strength

Chemical Composition (Example for 6061 Aluminum Alloy)

• Aluminum (Al): 95.8-98.6%
• Magnesium (Mg): 0.8-1.2%
• Silicon (Si): 0.4-0.8%
• Iron (Fe): 0.7% max
• Copper (Cu): 0.15-0.40%
• Chromium (Cr): 0.04-0.35%

Mechanical Properties (Example for 6061-T6)

• Tensile Strength: 310 MPa
• Yield Strength: 276 MPa
• Elongation: 8-12%
• Hardness: 95 Brinell

Applications

• Construction and Architecture: Used in structural components, roofing, and facade panels for its strength and aesthetic appeal.
• Automotive and Aerospace: Ideal for body panels, structural supports, and other components where weight and durability are critical.
• Marine Industry: Used in boat hulls, decks, and other components exposed to harsh marine environments due to its corrosion resistance.
• Industrial Fabrication: Employed in the production of equipment, machinery parts, and enclosures, offering ease of fabrication and reliable performance.

Conclusion

The 3 16 aluminum sheet is a highly reliable and versatile material that meets the demands of various industries. Its combination of strength, lightweight properties, and corrosion resistance makes it an ideal choice for applications ranging from construction to automotive and marine uses. With customizable dimensions and a range of tempers available, this aluminum sheet can be tailored to meet the specific needs of any project.
